Control4 app Supports up to 50 iOS and Android devices
OvrC Hub Built-in OvrC Pro functionality
Music Services Pandora, Napster, Spotify, TuneIn, TIDAL, Deezer, SiriusXM, SOUNDMACHINE, iHeartRadio,
Amazon Music, Radio.com, Qobuz
Apple Support Airplay-enabled devices
Inputs/Outputs - AV
Video Out 1 video out—HDMI
Video Out HDMI 2.0a output; 4K @ 60Hz
Audio Out 4 audio out - HDMI, 2 stereo analog, and Digital Coax
Audio In 1 audio in - dig coax
Audio Playback AAC, AIFF, ALAC, FLAC, M4A, MP2, MP3, MP4/M4A, Ogg Vorbis, PCM, WAV, WMA
Audio Resolution Up to 192 kHz / 24 bit
Inputs/Outputs - Network
Ethernet 10/100/1000BaseT compatible (required for controller setup)
1 Ethernet/POE+ in port, 1 Ethernet out port
WiFi Accessory only via USB
WiFi Security WPA/WPA2
WiFi Antena Accessory only via USB
Zigbee Pro 802.15.4
Zigbee Antenna External reverse SMA connector
Zwave Zwave 700 series
Zwave Antenna External reverse SMA connector
USB Port 1 USB 2.0 port
Inputs/Outputs - Control
IR out 6 IR out - 5V 27ma max output
IR capture 1 IR receiver—front; 20-60 kHz
Serial out 3 serial out (shared with IR out 1-3)
Contacts 1x; 2-30VDC input, 12VDC 125mA max output
Relays 1x; AC: 36V, 2A max across relay; DC: 24V, 2A max across relay
Power
Power requirements 100-240VAC, 60/50Hz, POE+
Power consumption Max: 18W, 61 BTUs/hour, Idle: 12W, 41 BTUs/hour
Other
Temperature Operating: 32 - 104 F (0 - 40 C) Storage: 4 - 158 F (-20 - 70 C)
Fan dB level No fan
Dimensions (H x W x D) 1.68” (42.9mm) X 8.63” (220mm) X 5.5” (140mm)
Weight 2.1 lbs (0.95 kg)
Other - Mechnical and Hardward
Front Panel LEDs Status LEDs (listed left to right): music streaming, warning, link, power
ID Button Includes LED that mimics the power LED on the front panel
CPU i.MX8Mi Quad Core
RAM 2GB Minimum
Flash Disk 16GB eMMC
Security Secure Boot
OSD QT OSD
Accessories
Wall-Mount Bracket C4-CORE3-WM
3.5mm to DB9 Serial Cable C4-CBL3.5-DB9
Remote for OnScreen Menu C4-SR260-B
4Sight Subscription (1 Year) C4-4Sight-E
