Dolby Atmos®, Dolby Surround Upmixer supports DTS Formats
Yes
Dolby Atmos Height Virtualizer
Yes
Dolby® TrueHD, Dolby Digital Plus
Yes
DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS 96/24, DTS-ES, DTS Express
Yes
DSD Disc (SACD) Playback
via HDMI (2.8 MHz/2 ch, 5.1 ch)
Digital Quad-Core 32-bit DSP (Cirrus Logic) + Aureus™ floating-point DSP (TI)
Yes
192 kHz/24-bit D/A Conversion for Hi-Res Audio
Yes
Enhanced Audio Return Channel (eARC) on HDMI Out (Main)
Yes
Advanced MCACC Auto Room Tuning
Auto Phase Control Plus • Subwoofer EQ • Multi-point Standing Wave Control
Dirac Live® Room Correction
Yes
Advanced Sound Retriever (2ch)
Yes
Advanced Surround Modes
Classical, Unplugged, Entertainment Show, Drama, Advanced Game, Action, Rock/Pop, Sports, Extended Stereo, Mono Music, Front Stage Surround Advance
Support HDMI 2.1*1 with 8K
VRR (Variable Refresh Rate), ALLM (Auto Low Latency Mode), QFT (Quick Frame transport), DSC (Display Stream Compression), and QMS (Quick Media Switching) pass-through
Supports HDR10+
HDR10, and HLG; 8K/60p (4:2:0/10-bit), 8K/30p (4:4:4/10-bit, 4:2:2/12-bit), 4K/120p (4:4:4/10-bit, 4:2:2/12-bit), 4K60p (4:4:4/12-bit) and BT.2020 color; DeepColor™ (36-bit), “x.v.Color”, LipSync, and HDCP 2.3
Dolby Vision Compatible
Yes
Ultra HD Upscaling (4K to 8K, 1080p to 8K/4K)
Yes
Works with Alexa supporting multi-room music
Yes
Works with Hey Google and Chromecast built-in
Yes
DTS Play-Fi with Pioneer Music Control App
Yes
Apple AirPlay 2 with Siri Voice Control
Yes
Works with SONOS supporting multiple Sonos Connect control and Volume Pass Through mode
Yes
Amazon Music HD*3, Pandora®, Spotify, TIDAL, and Deezer Hi-Fi Music-Streaming Services Ready
Yes
Internet Radio with TuneIn
Yes
Hi-Res Audio File Playback via USB/Network
Yes
Up to 192 kHz/24-bit ALAC*5, AIFF, FLAC, WAV (RIFF) and 11.2 MHz DSD*
Yes
Dual Band (5 GHz/2.4 GHz) Wi-Fi® Built-in
Yes
Bluetooth® Wireless Technology
Transmitter/Receiver (Version: 4.2, Profile: A2DP 1.2/AVRCP 1.3, Codec: SBC/aptX/aptX HD (TX), SBC/AAC(RX)) Built-in
Pioneer Remote App
Ready for Multi-room Entertainment Control and Network Streaming
User-Friendly GUI with System Setup Menu
Yes
On-Screen Information for Audio, Video and Network
Yes
Auto Power Off in HDMI Standby Through
Yes
AM/FM Tuner 40 Presets
Yes
User-Friendly Simple Remote Control
Yes
USB 1 In for USB Drive
Yes
MCACC/Dirac Live Web Setup MIC
Yes
Phones 1 Out
Yes
HDMI 2 Out
1 for MAIN, 1 for SUB/ZONE 2
USB 1 In for USB Drive
Yes
ZONE 2 Pre/Line Out/ZONE B Line Out
Yes
Speaker 9 ch Out
FRONT, CENTER, SURROUND, HEIGHT 1/Bi-AMP/ZONE 2, SURROUND BACK/HEIGHT 2/ZONE 3
FM/AM Antenna
Yes
Power Requirements
AC 120 V, 60 Hz
Power Consumption/Standby
750 W/0.1 W
Dimensions
17-1/8 x 6-13/16 x 14-9/16 inches (435 x 173 x 370.5 mm)
Weight
22.9 lbs. (10.4 kg)
Carton Dimensions
21-1/8 x 10-7/16 x 18-1/16 inches (536 x 265 x 458 mm)
Carton Included Weight
29.8 lbs. (13.5 kg)
