Built-in temperature sensor
Multi-page control, dedicated page for floor heating, air conditioning, and music control
Adjustable LCD backlight
Icon for key buttons can be changed by user
Button combination and double button combination function supported
The working voltage of the DLP panel is provided by the wireless power interface and a DLP panel can control 4 wireless power interfaces (for example, 3CH Wireless Switch Power Interface, 3CH Wireless Dimming Power Inter-face ) at the same time
The panel adopts Buspro Wireless communication and works in conjunction with wireless mesh gateway
Various key modes: Invalid, Single on/off, Single on, Single off, Combination on, Combination off, Combination on/off, Double click/Single on/off, Double click/Combination on/off, Momentary, Alarm clock, Short/long press, Short press/Long momentary press
Various key control types: Scene, Sequence, Timer switch, Universal switch, Single channel lighting control, Broad-cast scene, Broadcast channel, Curtain control, GPRS control, Panel control, Security module, Music control, Uni-versal control, Link page, DALI area dimming, IR control, Logic RGB adjustment, Logic scene etc
Online update supported
