Control4 app license Included—Supports up to 50 devices
Streaming services Pandora®, Napster®, Spotify, TuneIn, TIDAL, Deezer
ShairBridge Up to 20 instances of the driver in the project
5 concurrent streams
Inputs / Outputs
Video out 1 video out—HDMI
Video HDMI 1.4 output; HD 1080p, 50-60 Hz
Audio out 5 audio out—1 HDMI, 2 stereo analog, 2 digital coax
Audio in 4 audio in—2 stereo analog, 2 digital coax
Audio playback formats AAC, AIFF, ALAC, FLAC, M4A, MP2, MP3, MP4/M4A, Ogg
Vorbis, PCM, WAV, WMA
High-resolution audio playback Up to 192 kHz / 24 bit
Advanced audio subsystem Dual audio signal processors, multiple sample rate converters
Audio system controls (analog or digital coax) 10-band graphic equalizer, input gain, output gain, loudness,
tone controls, balance
Signal-to-noise ratio <-118 dBFS
Total harmonic distortion 0.00023 (-110 dB)
Network
Ethernet 10/100/1000BaseT compatible (required for controller setup)
Built-in Ethernet switch 1 Ethernet in + 4 gigabit Ethernet switch ports
WiFi Internal Dual-Band Wireless-N (EA-5 V1)
(2.4 GHz, 5 GHz, 802.11n/g/b)
Optional Dual-Band WiFi USB Adapter (EA-5 V2)
(2.4 GHz, 5 Ghz, 802.11ac/b/g/n/a)
WiFi security WPA/WPA2
WiFi antenna External reverse SMA connector (EA-5 V1 only); optional WiFi
adapter on the EA-5 V2
ZigBee Pro 802.15.4
ZigBee antenna External reverse SMA connector
eSATA port 1 eSATA port
USB port 1 USB 2.0 port—500mA
Control
IR out 8 IR out—5V 27mA max output, 1 IR blaster—front
IR capture 1 IR receiver—front; 20-60 kHz
Serial out 4 serial out (2 DB9 ports and 2 shared with IR out 1-2)
Contact 4 contact sensors—2V-30VDC input,
12VDC 125mA maximum output
Relay 4 relays—AC: 36V, 2A maximum voltage across relay;
DC: 24V, 2A maximum voltage across relay
Dimensions (H × W × D) 49 mm × 44.4 mm × 25.8 mm
Weight 3.1 kg
